Product Description
Key Features
♦Longer Cycle Life
Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership
♦Lighter Weight
About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries
♦Higher Power
Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity
♦Wider Temperature Range
-20ºC~60ºC
♦Superior Safety
Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation
Applications
♦Wheelchairs and scooters
♦Solar/wind energy storage
♦Back-up power for small UPS
♦Golf trolleys & buggies
♦Electric bikes
| Nominal Parameters | Voltage | 48V |
| Capacity | 200Ah | |
| Energy | 9.6kWh | |
| Dimensions(L x W x H) | 680x480x180 mm | |
| Weight | 96.5kg | |
| Basic Parameters | Life time(25ºC) | 20 years |
| Life cycles(80% DOD,25°C) | 6000 Cycles | |
| Storage time / temperature | 5 months @ 25°C 3 months @ 35°C 1 month @ 45°C | |
| Operation temperature | -20°C to 60°C @60+/-25% Relative Humidity | |
| Storage temperature | 0°C to 45°C @60+/-25% Relative Humidity | |
| Lithium Battery Standard | UL1642(Cell) , IEC62619,UN38.3, MSDS ,CE-EMC | |
| Enclosure protection rating | IP21 | |
| Electrical parameter | Operation voltage | 48 VDC |
| Max.charging voltage | 54 VDC | |
| Cut-off Discharge Voltage | 42 VDC | |
| Max.charging and discharging current | 120A(5760W) |
